Service and Maintenance 1
Keysight E36200 Series Service Guide 37
13 Remove two screws from the insulator using a
T10 bit. Remove the insulator.
14 Detach the AC inlet connector from the PSU
module.
15 Detach the power PSU connectors from the
mainboard.
Step Instructions Visuals
