1 Service and Maintenance
42 Keysight E36200 Series Service Guide
For E36234A models only
Step Instructions Visuals
1 Remove the side trims from the front panel.
2 Remove four screws from the front panel using a
T10 driver (two screws on each side).
3 Remove the top panel. Slide the top panel
towards the rear and lift it up.
To Next Page
