Performance Verification 2
Series E4360 Service Guide 21
Test Record Form – Keysight E4361A-J01
Keysight Model E4361A-J01 Report No _______________ Date __________________
Description Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
Voltage Programming & Readback
Min. Voltage Vout
Voltage measured over interface
High Voltage Vout
Voltage measured over interface
− 22 mV
Vout − 22 mV
53.438 V
Vout − 64.8 mV
__________
__________
__________
__________
+ 22 mV
Vout + 22 mV
53.562 V
Vout + 64.8 mV
CV Load Effect
− 2 mV
__________ + 2 mV
CV Source Effect
− 2 mV
__________ + 2 mV
CV Ripple and Noise (at full and no load)
peak-to-peak (Fixed mode)
rms (Fixed mode)
peak-to-peak (SAS & Table mode)
rms (SAS & Table mode)
N/A
N/A
N/A
N/A
__________
__________
__________
__________
+ 150 mV
+ 24 mV
+ 125 mV
+ 20 mV
Constant Current Tests
Current Programming & Readback
Min. Current Iout
Current measured over interface
High Current Iout
Current measured over interface
−Current measured over interface
− 22 mA
Iout − 23 mA
9.2594 A
Iout − 41.6 mA
Iout − 55 mA
__________
__________
__________
__________
__________
+ 22 mA
Iout + 23 mA
9.3406 A
Iout + 41.6 mA
Iout + 55 mA
CC Load Effect
− 1 mA
__________ + 1 mA
CC Source Effect
− 1 mA
__________ + 1 mA
Test Description E4361A-J01 Setting
Voltage Programming & Readback, Min 0 mV, 9.48 A
Voltage Programming & Readback, High 53.5 V, 9.48 A
CV Load Effect, Source Effect, Ripple and Noise 53.5 V, 9.48 A; Rload for ripple & noise= 5.75Ω
Current Programming & Readback, Min 0 mA, 54.8 V
Current Programming & Readback, High 9.3 A, 54.8 V
CC Load Effect, Source Effect 9.3 A, 54.8 V
SAS Curve settings for Ripple and Noise tests Isc = 9.3; Imp = 9.3; Vmp = 53.5; Voc = 58
