Keysight Technologies E4360A - Page 28

2 Performance Verification
28 Series E4360 Service Guide
Test Record Form – Keysight E4362A-J03 and E4362A-J52
Keysight Model E4362A-J03 & E4362A-
J52
Report No _______________ Date __________________
Description Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
Voltage Programming & Readback
Min. Voltage Vout
Voltage measured over interface
High Voltage Vout
Voltage measured over interface
− 42 mV
Vout − 42 mV
99.883 V
Vout − 122 mV
__________
__________
__________
__________
+ 42 mV
Vout + 42 mV
100.117 V
Vout + 122 mV
CV Load Effect
− 2 mV
__________ + 2 mV
CV Source Effect
− 2 mV
__________ + 2 mV
CV Ripple and Noise (at full and no load)
peak-to-peak (Fixed mode)
rms (Fixed mode)
peak-to-peak (SAS & Table mode)
rms (SAS & Table mode)
N/A
N/A
N/A
N/A
__________
__________
__________
__________
+ 150 mV
+ 28 mV
+ 172 mV
+ 23 mV
Constant Current Tests
Current Programming & Readback
Min. Current Iout
Current measured over interface
High Current Iout
Current measured over interface
−Current measured over interface
− 12 mA
Iout − 12 mA
5.976 A
Iout − 24 mA
Iout − 31 mA
__________
__________
__________
__________
__________
+ 12 mA
Iout + 12 mA
6.024 A
Iout + 24 mA
Iout + 31 mA
CC Load Effect
− 1 mA
__________ + 1 mA
CC Source Effect
− 1 mA
__________ + 1 mA
Test Description E4362A-J03 & E4362A-J52 Setting
Voltage Programming & Readback, Min 0 mV, 6.12 A
Voltage Programming & Readback, High 100 V, 6.12 A
CV Load Effect, Source Effect, Ripple and Noise 100 V, 6.12 A; Rload for ripple & noise = 16.7 Ω
Current Programming & Readback, Min 0 mA, 102.5 V
Current Programming & Readback, High 6 A, 102.5 V
CC Load Effect, Source Effect 6 A, 102.5 V
SAS Curve settings for Ripple and Noise tests Isc = 6; Imp = 6; Vmp = 100; Voc = 108
