2 Performance Verification
30 Series E4360 Service Guide
Test Record Form – Keysight E4362A-J05
Keysight Model E4362A-J05 Report No _______________ Date __________________
Description Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
Voltage Programming & Readback
Min. Voltage Vout
Voltage measured over interface
High Voltage Vout
Voltage measured over interface
− 37 mV
Vout − 37 mV
87.5972 V
Vout − 107 mV
__________
__________
__________
__________
+ 37 mV
Vout + 37 mV
87.8028 V
Vout + 107 mV
CV Load Effect
− 2 mV
__________ + 2 mV
CV Source Effect
− 2 mV
__________ + 2 mV
CV Ripple and Noise (at full and no load)
peak-to-peak (Fixed mode)
rms (Fixed mode)
peak-to-peak (SAS & Table mode)
rms (SAS & Table mode)
N/A
N/A
N/A
N/A
__________
__________
__________
__________
+ 150 mV
+ 27 mV
+ 158 mV
+ 22 mV
Constant Current Tests
Current Programming & Readback
Min. Current Iout
Current measured over interface
High Current Iout
Current measured over interface
−Current measured over interface
− 15 mA
Iout − 15 mA
6.2724 A
Iout − 27.6 mA
Iout − 38 mA
__________
__________
__________
__________
__________
+ 15 mA
Iout + 15 mA
6.3276 A
Iout + 27.6 mA
Iout + 38 mA
CC Load Effect
− 1 mA
__________ + 1 mA
CC Source Effect
− 1 mA
__________ + 1 mA
Test Description E4362A-J05 Setting
Voltage Programming & Readback, Min 0 mV, 6.426 A
Voltage Programming & Readback, High 87.7 V, 6.426 A
CV Load Effect, Source Effect, Ripple and Noise 87.7 V, 6.426 A; Rload for ripple & noise = 13.8 Ω
Current Programming & Readback, Min 0 mA, 89.9 V
Current Programming & Readback, High 6.3 A, 89.9 V
CC Load Effect, Source Effect 6.3 A, 89.9 V
SAS Curve settings for Ripple and Noise tests Isc = 6.3; Imp = 6.3; Vmp = 87.7; Voc = 95
