Keysight N9927-90001 User’s Guide 117
Time Domain – Option 010
Trace Settings
Trace Settings
The following two settings apply to specific traces.
Transform Enable
Enable Time Domain transform for the specific trace.
— Select the trace.
—Press Measure Setup 4
—Then Transform
— Then choose from:
— Transform On
Trace displays Time Domain data.
— Transform Off
Trace displays frequency domain data.
Gate Enable
Enable Gating for the specific trace.
— Select the trace.
—Press Measure Setup 4
—Then Transform
— Then choose from:
— Gating On
Trace displays Time Domain data.
— Gating Off
Trace displays frequency domain data.
