100 Keysight FieldFox Handheld Analyzers Service Guide
Replaceable Parts
Replaceable Parts Listings
6-
Case Group
1
Refer to Figure 6-5 for part locations.
1. Each time the FieldFox case is opened for any reason, you must order a Repair and Re-assembly Kit. See
“Miscellaneous Parts” on page 103.
Reference
Designator
Part Number Qty Description
Replacement Assemblies
(2) N9927-60116 1 Front Enclosure Assembly—Includes:
Front case, W1312-40049, with A1 keypad installed (2)
LCD lens filter (3)
Keypad overlay, N9912-80005 (4)
(7) N9927-60119 1 Left Side I/O Panel Assembly—Includes:
Speaker
(8) N9927-60120 1 Right Side I/O Panel Assembly -- Includes:
Doors (USB, SD, LAN)
(11) N9927-60117 1 Rear Enclosure Assembly—Includes:
Rear case (11)
(15) N9912-60028 1 Kick Stand Assembly—Includes:
Kickstand, W1312-40065 (15)
Friction hinge and spacer (14)
Screw (for hinge), qty 4 (13)
Hinge cover (16)
Screw (for hinge cover), qty 4 (17)
