Keysight Technologies J-BERT M8020A Configuration Guide

Step 10 Choose calibration and service plan
Option-No Description
R-50C-011-3 Calibration Assurance Plan – Return to Keysight – 3 years
R-50C-011-5 Calibration Assurance Plan – Return to Keysight – 5 years
R-1380-M8000 Productivity assistance
PS-S10 Remote scheduled productivity assistance. Select 1 to 999 hours.
PS-S20 Startup assistance (day)
Upgrades for J-BERT M8020A High-performance BERT
All upgrades all license upgrades without return-to-factory.
M8020AU Upgrades to J-BERT High-performance BERT modules
Upgrades for M8041A
M8041A-U14 Upgrade of M804A-0S1 to 0S4, interactive link training for PCI Express 8 GT/s and 16 GT/s, clockgroup-wide license
M8041A-U16 Upgrade to 16 Gb/s data rate from M8041A-G08 and M8041A-C08, module-wide license
M8041A-UA2 Upgrade of M8041A to second channel for analyzer, license
M8041A-UA3 Upgrade of M8041A to analyzer equalization, module-wide license
M8041A-UED Upgrade to BERT from M8041A-G08 and M8041A-G16, module-wide license
M8041A-UG2 Upgrade of M8041A to second channel for pattern generator, license
M8041A-UG3 Upgrade of M8041A to advanced jitter sources for receiver characterization, module-wide license
M8041A-UG4 Upgrade of M8041A to multi-tap de-emphasis, module-wide license
M8041A-UG5 Upgrade of M8041A to adjustable intersymbol interference (ISI) for all S/N, module-wide license
1
M8041A-UG6 Upgrade of M8041A to reference clock input with multiplying PLL, clockgroup-wide license
M8041A-UG7 Upgrade of M8041A to advanced interference sources for receiver characterization, module-wide license
M8041A-UR3 Upgrade of M8041A-0A3 with latest CTLE presets, return-to-factory
M8041A-UR5 Upgrade of M8041A to Adjustable ISI. Option M8041A-UR5 only available for S/N below DE55300500, return-to-factory
M8041A-US1 Upgrade of M8041A to interactive link training for PCI Express, clockgroup-wide license
M8041A-US2 Upgrade of M8041A to SER/FER analysis for coded and retimed loopback, clockgroup-wide license
M8041A-US3 Upgrade of M8041A to interactive link training for USB 3.0 and USB 3.1, clockgroup-wide license
M8041A-US4 Upgrade of M8041A to interactive link training for PCI Express 8 GT/s and 16 GT/s, clockgroup-wide license
M8041A-USX Upgrade of M8041A to 10GBASE-KR transmitter equalization training, module-wide license
M8041A-US6 Upgrade of M8041A to SAS-3 transmitter equalization training, module-wide license
2
Upgrades for M8051A
M8051A-U16 Upgrade to 16 Gb/s data rate from M8051A-G08 and M8051A-C08, module-wide license
M8051A-UA2 Upgrade of M8051A to second channel for analyzer, license
M8051A-UA3 Upgrade of M8051A to analyzer equalization, module-wide license
M8051A-UED Upgrade to BERT from M8051A-G08 and M8051A-G16, module-wide license
M8051A-UG2 Upgrade of M8051A to second channel for pattern generator, license
M8051A-UG3 Upgrade of M8051A to advanced jitter sources for receiver characterization, module-wide license
M8051A-UG4 Upgrade of M8051A to multi-tap de-emphasis, module-wide license
M8051A-UG5 Upgrade of M8051A to adjustable intersymbol interference (ISI) for all S/N, module-wide license
1
M8051A-UG7 Upgrade of M8051A to advanced interference sources for receiver characterization, module-wide license
M8051A-UR3 Upgrade of M8051A-0A3 with latest CTLE presets, return-to-factory
M8051A-UR5 Upgrade of M8051A-UR5 to Adjustable ISI. Option M8051A-UR5 only available for S/N below DE55300500, return-to-factory
M8051A-US6 Upgrade of M8051A to SAS-3 transmitter equalization training, module-wide license
2
M8051A-USX Upgrade of M8051A to 10GBASE-KR transmitter equalization training, module-wide license
1. For serial numbers < DE55300500 this upgrade requires return-to-factory.
2. Requires option M8041A-0G4 to allow de-emphasis negotiation.
07 | Keysight | J-BERT M8020A High-Performance BERT - Configuration Guide 3.6
