Step 8 Test Automation Software for PCIe, USB, SATA DisplayPort, Thunderbolt, SD UHS-II RX test with M8000, is not part of the
J-BERT M8020A structure. Don’t forget to order, if needed
Option-No Description
N5990A-010 Required option
N5990A-101 Support for PCI Express Gen1, Gen2 and Gen3 receiver tests for J-BERT M8020A
N5990A-102 Support for USB 2.0 and USB 3.0 receiver tests for J-BERT M8020A (USB 3.0 only)
N5990A-103 Support for SATA 1.0, 2.0 and 3.0 RSG tests for J-BERT M8020A
N5990A-10 4 Support for Thunderbolt receiver tests
N5990A-105 Support for SAS-3/SAS-4 tests
N5990A-120 Support for SD UHS-II receiver tests
N5990A-155 DisplayPort receiver test for J-BERT M8020A
N5990A-165 MIPI M-PHY receiver test for J-BERT M8020A
N5990A-301 PCI Express 3.0 link training suite for J-BERT M8020A
N5990A-302 USB 3.0 and 3.1 link training suite for J-BERT M8020A
N5990A-303 SATA link training suite for J-BERT M8020A
N5990A-305 SAS-3/SAS-4 link training suite for J-BERT M8020A
N5990A-365 MIPI M-PHY frame generator for J-BERT M8020A or 13.5 Gb/s
N5990A-366 MIPI M-PHY Frame Generator for J-BERT M8020A
N5990A-368 MIPI M-PHY Protocol-Specific Macros for LLI, SSIC and DigRF v4 for J-BERT M8020A
N5990A-501 PCI Express link equalization tests
Step 9 Choose accessories
Option Description
M8041A-801 Matched cable pair, 2.92 mm (m f), 0.85 m (This 2.92 mm cable is compatible with 3.5 mm front panel connectors of M8041A/51A)
M8041A-802 Bandpass filter 11.4 to 15.6 GHz, SMA (For M8061A clock path to minimize intrinsic RJ of M8061A for data rate of 25.78 Gb/s)
M8041A-803 Bandpass filter 11.1 to 17.5 GHz, SMA (For M8061A clock path to minimize intrinsic RJ of M8061A for data rates at 25.0 to 32.0 Gb/s)
M8048A-001 ISI channels, four short traces, 8 to 13 inches
M8048A-002 ISI channels, four long traces, 14 to 34 inches
M8048A-801 Short matched cable pair, SMA (f) to SMA (f) for cascading M8048A ISI channels
M8051A-801 Clock distribution cable for M8051A
15442A Four SMA cables, unmatched
N4910A Matched cable pair, 85 cm long, 2.4 mm (m f) to 2.4 mm (m f) for data outputs and inputs
8490D 2.4mm (m f) 6 dB attenuator, 50 GHz (when data outputs is driving into non- 50 Ω inputs and for over-voltage protection,
e.g. for some high-performance oscilloscopes)
N9398F 2.4mm (m) DC block, 50 GHz (when data output drives into a single ended, AC coupled input, such as 81490A ref. transmitter)
Y1225A Rack-mount kit for AXIe 2-slot chassis M9502A 5-slot AXIe chassis (alternatively to M8061A-BU2) with USB option M9505A-U20
Y1226A Rack-mount kit for AXIe 5-slot chassis M9505A
Note: Content of default accessories included in shipment.
06 | Keysight | J-BERT M8020A High-Performance BERT - Configuration Guide 3.6
