Keysight Technologies J-BERT M8020A Configuration Guide

Publication title Pub number
M8020A J-BERT High-Performance BERT - Data Sheet 5991-3647EN
M8048A ISI Channel - Data Sheet 5991-3648EN
M9052A and M9505A 2-and 5 slot AXIe Chassis - Data Sheet 5990-6584EN
M8061A Multiplexer with De-Emphasis - Data Sheet 5991-2506EN
M8062A 32 Gb/s Front-End for J-BERT M8020A High-Performance BERT - Data Sheet 5992-0987EN
M8040A High-Performance BERT 64 GBaud - Data Sheet 5992-1525EN
M8030A Multi-channel BERT - Data Sheet 5992-1287EN
M9505A AXIe Chassis 5-slot - Data Sheet 5990-6584EN
N1076A/N1077A Electrical and Optical Clock Data Recovery Solutions - Data Sheet 5992-1620EN
N4877A and N1075A CDR/Demux - Data Sheet 5990-9949EN
Master Your MIPI M-PHY Receiver Test Using J-BERT M8020A - Application Brief 5991-3959EN
How to Pass Receiver Test According PCI Express CEM Specification - Application Note 5990-9208EN
Accurate Calibration of PCIe 3.0 Receiver Stress Signals - Application Note 5990-6599EN
How to Test a MIPI M-PHY High-speed Receiver- Application Note 5991-2848EN
Master Your Next PCIe3 Receiver Test Using J-BERT M8020A - Application Note 5991-4190EN
Master Your Next USB 3.x Designs with J-BERT M8020A - Application Note 5991-4357EN
Characterizing and Verifying Compliance of 100 Gb Ethernet Components and Systems - Application Note 5992-0019EN
Upgrades for M8061A
M8061A-U04 Upgrade of M8061A to 4-tap de-emphasis, module-wide license
M8061A-U08 Upgrade of M8061A to extension to 8-tap de-emphasis, module-wide license
Upgrades for M8062A
M8062A-UA3 Upgrade of M8062A to analyzer equalization, license
M8062A-UA4 Upgrade of M8062A to clock recovery, license
M8062A-UED Upgrade to 32 Gb/s BERT front end from M8062-G32, License
M8062A-UG4 Upgrade of M8062A to multi-tap De-emphasis, License
M8062A-UG5 Upgrade of M8062A to adjustable intersymbol interference, license
M8062A-US6 Upgrade of M8062A to SAS-3 transmitter equalization training, module-wide License
1
M8062A-USC Upgrade of M8062A to 100GBASE-KR4 and 25GBASE-KR transmitter equalization training, module-wide license
Related literature
1. Requires option M8041A-0G4 to allow de-emphasis negotiation.
Default Accessories Included With Shipment
– M8041A module: eight 50 Ω terminations, commercial calibration report (“UK6”), certificate of calibration, ESD protection kit.
– M8051A module: four 50 Ω terminations, clock synchronization cable (M8051A-801), commercial calibration report (“UK6”),
certificate of calibration
– M8061A module: see M8061A data sheet
– M8062A Module: two 50 Ω terminations, clock synchronization cable, semi-rigid interconnect cable set, commercial calibration
report (“UK6”), certificate of calibration.
– M8020A-BU1: M9505A AXIe chassis with embedded controller, USB cable, getting started guide, AXIe filler panel, power cord
– M8020A-BU2: M9505A AXIe chassis, USB cable, getting started guide, AXIe filler panel, power cord
– M8070A: CD-ROM with M8070A system software
08 | Keysight | J-BERT M8020A High-Performance BERT - Configuration Guide 3.6
