PNA Family Network Analyzer Upgrade Kits
Frequency, test ports, test set and power configurations
Upgrade kits are available to add options after initial purchase. To upgrade the PNA-X/PNA/PNA-L, order the corresponding
item number. The model and serial numbers of the instrument to be retrofitted are required as part of the order.
1. Frequency upgrade options from 8.5/13.5/20/26.5 GHz to 43.5/50 GHz and 43.5/50 GHz to 67 GHz are not available. Trade-in is recommended.
2. Not available on N5227A.
3. Not available on N5249A or N5247A
Description Required Option
For PNA-X
Series
For PNA
Series
For PNA-L
Series
User
Installable
Frequency upgrade
1
Extend analyzer's frequency range to 13.5 GHz N5239A or N5249A N5249AU-913 n/a N5239AU-613 No
Extend analyzer's frequency range to 20 GHz N5239A or N5231A n/a n/a N5239AU/31AU-620 No
Extend analyzer's frequency range to 26.5 GHz N5241A, N5249A, or
N5221A
N5241AU-960/
49AU-960
N5221AU-626 n/a No
Extend analyzer's frequency range to 50 GHz N5244A, N5224A or
N5234A
N5244AU-990 N5224AU-650 N5234AU-650 No
Test ports
Expand 2-ports, single source without
congurable test set to 4-ports
N522xA-200 n/a N522xAU-600 n/a No
Expand 2-ports, single source with
congurable test set to 4-ports
N524xA-200 or
N522xA-201
N524xAU-940 N522xAU-601 n/a No
Expand 2-ports, single source with
congurable test set and extended power range to 4-ports
N522xA-217 n/a N522xAU-617 n/a No
Expand 2-ports, single source with
congurable test set, extended power range and bias-tees
to 4-ports
N524xA-219 or
N522xA-219
N524xAU-942 N522xAU-619 n/a No
Expand 2-ports, internal second source with congurable
test set, extended power range, bias-tees, combiner and
mechanical switches to 4-ports
N524xA-224 N524xAU-944 n/a n/a No
Test set and power conguration
Add congurable test set, 2-ports N522xA-200 n/a N522xAU-201 n/a No
Add congurable test set and source
attenuators, 2-ports
N523xA-200 n/a n/a N523xAU-216 No
Add extended power range, 2-ports
2
N522xA-201 n/a N522xAU-217 n/a No
Add bias-tees, 2-ports
2
N522xA-217 n/a N522xAU-219 n/a No
Add extended power range and bias-tees, 2-ports N524xA-200 or
N5227A-201
N524xAU-921 N5227AU-219 n/a No
Add internal 2nd source, combiner and
mechanical switches, 2-ports
N524xA-219 or
N522xA-219
N524xAU-922 n/a n/a No
Add high power congurable, 2-ports N524xA-219 or 224 N524xAU-H85
3
n/a n/a No
Add congurable test set, 4-ports N522xA-400 n/a N522xAU-401 n/a No
Add congurable test set and source
attenuators, 4-ports
N523xA-400 n/a n/a N523xAU-416 No
Add extended power range, 4-ports
2
N522xA-401 n/a N522xAU-417 n/a No
Add bias-tees, 4-ports
2
N522xA-417 n/a N522xAU-419 n/a No
Add extended power range and bias-tees, 4-ports N524xA-400 or
N5227A-401
N524xAU-926 N5227AU-419 n/a No
Add internal 2nd source, combiner and
mechanical switches, 4-ports
N524xA-419 or
N522xA-419
N524xAU-927 n/a n/a No
Add high power congurable, 4-ports N524xA-419 or 423 N524xAU-H85
3
n/a n/a No
