General Accessories, continued
Probe
– 85024A high-frequency probe; provides high-impedance
in-circuit test capability from 300 kHz to 3 GHz.
Power meters and sensors
1
Recommended for self support, adjustments and performance
tests to verify proper instrument operation.
USB power sensors
– U848x Series USB thermocouple power sensors (A.09.90.08
and later)
– U2020 X-Series USB peak and average power sensors
– U2000 Series USB power sensors
– U2040 X-Series USB and LAN power sensors
Power meters
– P Series power meters (N1911A and N1912A) and all
supported sensors
– EPM Series power meters (N1913A and N1914A) and all
supported sensors
– EPM-P Series power meters (E4416A and E4417A) and all
supported sensors
– E Series power meters (E4418 and E4419) and all supported
sensors
– HP 437B / 438A power meters
Comb generators
Two are required for NVNA. Also requires separate power supply.
– U9391C 10 MHz to 26.5 GHz comb generator
– U9391F 10 MHz to 50 GHz comb generator
– U9391G 10 MHz to 67 GHz comb generator
Amplifiers
– 83006A power amplifier, 10 MHz to 26.5 GHz, 20 dB gain,
power out: +18 dBm to 10 GHz or +16 dBm to 20 GHz or
+14 dBm to 26.5 GHz
– 83017A power amplifier, 50 MHz to 26.5 GHz, 25 dB gain,
power out: +20 dBm to 20 GHz, or +15 dBm to 26.5 GHz
– 83018A power amplifier, 2 to 26.5 GHz, 27 dB gain to 20 GHz
or 23 dB to 26.5 GHz, power out: +24 dBm to 20 GHz or
+21 dBm to 26.5 GHz
– 83020A power amplifier, 2 to 26.5 GHz, 30 dB gain to 20 GHz
or 27 dB to 26.5 GHz, power out: +30 dBm to 20 GHz or
+26 dBm to 26.5 GHz
– 83050A power amplifier, 2 to 50 GHz, 23 dB gain, power out:
+20 dBm to 40 GHz or +17 dBm to 50 GHz
– 83051A power amplifier, 45 MHz to 50 GHz, 23 dB gain power
out: +12 dBm to 45 GHz or +10 dBm to 50 GHz
1. For the latest guide to power meters and power sensors, refer to the
Keysight web site: www.keysight.com/find/powermeters
2. 5063-9224 is a complete rack mount kit with handles. N52xxA comes
with ruggedized handles, which must be replaced with classic handles
shipped with the kit. 1CN020A is a pair of classic handles, and used with
5063-9237 for mounting N52xxA to a rack.
Couplers
– 87300B coaxial coupler, 1 to 20 GHz, SMA (f), 10 dB
coupling
– 87300C coaxial coupler, 1 to 26.5 GHz, 3.5 mm (f), 10 dB
coupling
– 87301B coaxial coupler, 10 to 46 GHz, 2.92 mm (f), 10 dB
coupling
– 87301D coaxial coupler, 1 to 40 GHz, 2.4 mm (f) or optional
2.92 mm (f), 13 dB coupling
– 87301E coaxial coupler, 2 to 50 GHz, 2.4 mm (f), 10 dB
coupling
– 87310B 90
o
coaxial coupler, 1 to 18 GHz, SMA (f), 3 dB
coupling
Equipment rack accessories
– E3663AC Rail kit (included with Option 1CM and 1CP)
– 1CM042A Rack mount flange kit, for use without handles
(included with Option 1CM)
– 5063-9224 Rack mount flange kit with handles
2
– 5063-9230 Front handle kit
2
– 1CN020A Rack mount flange kit, for use with classic handles
(included with Option 1CP)
2
Monitors
– VGA-compatible monitor
Interface cables
Choose the appropriate cables to connect each peripheral to the
network analyzer.
– 10833A GPIB cable, 1.0 m (3.3 ft)
– 10833B GPIB cable, 2.0 m (6.6 ft)
– 10833D GPIB cable, 0.5 m (1.6 ft)
– 82357B GPIB to USB interface
