Parallel and Series Connections 65
Parallel Connections 65
Series Connections 67
Auxiliary Measurement Connections 70
Interface Connections 71
GPIB Connections 71
USB Connections 72
LAN Connections - site and private 72
Digital Port Connections 74
3 Getting Started 77
Using the Front Panel 78
Turn the Unit On 78
Select an Output Channel 78
Set the Output Voltage 79
Set the Output Current 79
Enable the Output 80
Use the Front Panel Menu 80
Remote Interface Configuration 83
USB Configuration 83
GPIB Configuration 83
LAN Configuration 84
Modifying the LAN Settings 85
Using the Web Interface 88
Using Telnet 89
Using Sockets 90
Securing the Interfaces 90
4 Operating the Power System 91
Programming the Output 92
Select a Channel View 92
Select an Output Channel 93
Set the Output Voltage 93
Set the Output Current 93
Set the Output Resistance 94
Set the Output Power 95
Set the Output Mode 96
Set the Slew Rate 96
Enable the Output 97
Sequence Multiple Outputs 98
Program the Output Relays 98
Set the Output Bandwidth 99
Set the Output Turn-Off Mode 100
Programming an Input Short 100
Enable Under-Voltage Inhibit 101
Stepping the Output 102
Synchronizing Output Turn-On 106
Synchronizing Output Turn-On Delays 106
Synchronizing Multiple Mainframes 109
Keysight N6700C Series User's Guide 4
