Installation Note N9030-90045 41
Option BBA, Analog Baseband I/Q Inputs Retrofit Kit
Adjustments and Performance Verification
Calibration Software and specified test equipment is required to perform the adjustments, and can be
used to automate the performance verification testing.
Information on how to obtain this software can be found at
http://www.agilent.com/find/calibrationsoftware
1. Perform the following adjustments, located in the TME field software.
• Absolute Amplitude (Option BBA) Adjustment
2. Perform the following performance verification tests using the TME field software:
• All Frequency Response Tests (if the switch and cables were disturbed)
• Absolute Amplitude Accuracy at 250 kHz (Option BBA)
• Frequency Response Below 250 kHz (Option BBA)
• Frequency Response Above 250 kHz (Option BBA)
• Channel Match (Option BBA)
IMPORTANT A full calibration is required to assure the instrument meets all specifications
The end user must ultimately determine whether they want a full calibration to be performed after the
installation of this upgrade or not. If a full calibration is required, arrangements regarding the level of
calibration must be made between the end user and the calibration provider.
If you require further assistance, please contact the Agilent support team.
Online assistance: http://www.agilent.com/find/assist
If you do not have access to the Internet, contact your local Agilent Technologies Sales and Service
Office, or if in the United States, call 1-800-829-4444
(8 am - 8 pm ET, Monday - Friday).
