Keysight P937 A Series Startup Guide

1-16 Keysight Technologies Startup Guide
Getting Started
STEP 4. Install the P937xA Network Analyzers
1-
Figure 1-8 Installing Semi-Rigid Cables from Option Y1701A—P9375-20013,
P9375-20014, and P9375-20015
Figure 1-9 Cable Removal Tool (part number 5002-3361)
You have now completed the hardware installation procedure.
If applicable, use the socket adapter tool (5023-1450) to remove the SMA
jumper cable P9375-20013. And, use the (5002-3361) tool for
P9735-20014, and NP9375-20015 SMB jumper cables. See Figure 1-9 on
page 16.
P9375-20014
Trig In to Trig Out
P9375-20013
LO In to LO Out
(Install last)
P9375-20015
(Ref In to Ref Out)
