KFI 105250 - Mount Plate Attachment; Drilling for Hardware; Bolt Plate Installation; Final Tightening and Tube Attachment

“Figure 5” Bolt Plate Location
“Figure 6” Mount Plate Final Install
“Figure 4” Skid Plate Drill Pattern
©2011 Copyright Kappers Fabricating, Inc. All rights reserved
2. PlaceMountPlateuptoMountPlate
Bracketandinstallusingthe3/8”-16x1
1/4”BoltsandLockWashers(B)asshown
inFigures4&6.
3. UsingtheMountPlateasatemplate,
drillouttheinsiderearholes(C)for3/8”
hardware.
4. InstalltheBoltPlateusingthe  
3/8”-16x33/4”BoltsandLockWashers
(D)asshowninFigures5&6.
5. Tightendownallbolts.
6. SeeUTVPlowTubeSysteminstruction
manualfortubeattachment.
