KFI 105250 - Plow Pulley System Recommendations; Synthetic Rope Plow Fairlead Pulley; Steel Cable Plow Fairlead Pulley; Benefits of Using a Pulley

THISMOUNTRECOMMENDSAPLOWPULLEY
WHENTHEWINCHFAIRLEADANDPLOW
PINPOINTARECLOSETOEACHOTHER,
ITCREATESASHALLOWLIFTINGANGLE.
BYADDINGAPULLEY,YOUARE
CHANGINGTHEWINCHANGLETOA
MOREVERTICALLIFTINGPOSITION.THIS
WILLPROVIDELESSSTRAINONTHE
WINCHANDENTIREPLOWSYSTEM.
WHYUSEAPULLEY?
1
2
3
possible POSITIONS
*STANDARD FAIRLEAD PULLEY REQUIRED
FOR ALL PUSH TUBE APPLICATIONS*
LIFTHOOK
POSITIONEDFOR
EXTRASUPPORT
12"SOFTLOOP
STRAP
HOOK
WINCH
PLOWFAIRLEAD
PULLEY
PINPOINT
12” SOFT LOOP STRAP WRAPS AROUND BUMPER OR
SOLID ANCHOR POINT ABOVE PULLEY.
12"SOFTLOOP
STRAP
HOOK
WINCH
PLOWFAIRLEAD
PULLEY
PINPOINT
-ALUMINUMROLLER -STANDARDORWIDE
SYNTHETIC ROPE PLOW FAIRLEAD PULLEY
-RECOMMENDAPULLEYATTHEWINCHASWELLASPUSHTUBE. VIEWEXAMPLEBELOW. -STEELROLLER -STANDARDORWIDE
STEEL CABLE PLOW FAIRLEAD PULLEY
or
