FZ-USV-230 (SXM 2540) [ENG]
Stand: 10.03.2008 page 21 from 21
6. Recommended Maintenance
It is recommended that the unit should be tested from the first “power up”, at least
once a year to verify continued correct operation. Please check all functions for correct
safety monitoring. Please check also the function of the Genius / Fliethomatic under
normal conditions and with different simulated errors for example, mains power (AC)
failure, battery disconnected.
Testing should also be in accordance with the following recommendations ;
Output Voltage Test
Voltage output should be tested under normal load conditions to verify correct levels.
Test the voltage when the Genius / Fliethomatic operates to lock or unlock the door.
Battery Test
Battery should be checked for full charge under normal load conditions. This test
should verify correct voltage at
a) battery terminals, and
b) battery output position on the circuit board to ensure the integrity of all inter-
connecting wiring.
It is recommended to replace the battery at least every 4 years.
Please give used batteries to the recycling, service company.
7. Battery Stand-By Mode Specifications
Standby 100
lock / unlock
200
lock / unlock
500
lock / unlock
Non-stop
operation
1 Genius 40 Hr 35 Hr 28 Hr 12 Hr 4 Hr
2 Genius 20 Hr 17 Hr 14 Hr 6 Hr 2 Hr
3 Genius 13 Hr 11 Hr 9 Hr 4 Hr 1,3 Hr
4 Genius 10 Hr 8 Hr 7 Hr 3 Hr 0,5 Hr
1 Genius with coupling relay 29 Hr 24 Hr 20 Hr 7 Hr 3 Hr
All data is approximate in the 24 VDC version with two 12 Volt batteries connected in
series, fully charged with a battery capacity of 7Ah.
