KHADAS Tone2 - Input and Output Sources; Balanced RCA Output Usage; S;PDIF Coaxial Input Usage; Bluetooth Module Input

Input / Output Sources
3
1
2
4
5
Computer / Smaphone/ SBC (data-in and power-in)
‘Khadas BT Magic’ Bluetooth audio receiver module / USB-C 5V linear power supply (power-in)
CD player (S/PDIF coax-in)
Pre-amp (analog out) -> Amp -> Hi-Fi speaker
Pre-amp (analog out) -> Amp -> Hi-Fi speaker
* The ‘Khadas BT Magic’ Bluetooth audio receiver module needs to be purchased separately.
1 2 3 4 5
