Fuse Name Fuse rating Circuit Protected
MULTI MEDIA 1 25A Low DC-DC Converter (Audio)
AIR BAG 15A SRS (Supplemental Restraint System) Control Module
INTERIOR LAMP 10A
Overhead Console Lamp, Center Room Lamp, Room Lamp, Vanity Lamp Switch Left Handle side/Right
Handle side, Luggage Lamp Left Handle side/Right Handle side, Glove Box Lamp, Driver/Passenger Door
Mood Lamp, Driver/Passenger Door Lamp, Driver/Passenger Foot Lamp
STOP LAMP 10A IBU, Stop Lamp Switch
CLUSTER 10A Instrument Cluster, Head-Up Display
E-SHIFTER 2 10A Electronic Auto Transmission Shift Lever (IG1)
IBU 4 10A IBU (IG1)
MULTI MEDIA 3 10A Instrument Cluster, Head-Up Display, Air Conditioner Switch
MULTI MEDIA 2 15A Audio
MEMORY 1 10A Air Conditioner Control Module, Air Conditioner Switch, Security Indicator, Head-Up Display
IBU 3 10A IBU (B+)
Instrument panel (Driver’s side fuse panel)
