Fuse Name Fuse rating Circuit Protected
E-SHIFTER 1 10A Electronic Auto Transmission Shift Lever (B+)
A/BAG IND. 10A Instrument Cluster, Passenger Air Bag IND.
IBU 1 15A IBU (B+)
DAU 10A Driver Door Module, Driver/Passenger Power Outside Mirror
MODULE 2 10A IBU (IG2)
MODULE 3 10A Auto Transmission Shift Lever Switch, Driver Door Module, Stop Lamp Switch
DOOR LOCK 20A Door Lock Relay, Door Unlock Relay, Two Turn Unlock Relay
S/HEATER
DRV/PASS
25A Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module
TAIL GATE 10A Tail Gate Lid Relay, Fuel Lid Relay, Crash Pad Switch
IBU 2 10A Rain Sensor
POWER OUTLET 1 20A Front Power Outlet #2
