Fuse Name Fuse rating Circuit Protected
ALT
175A
200A
Alternator, Multi Fuse
- COOLING FAN 1 / B+5 / B+4 / B+3 / OPCU / ESC1 / ESC2 / BLOWER / POWER TAIL GATE
COOLING FAN 2 125A [BLDC (Brushless Direct Current) Motor] Cooling Fan Controller
START 30A Start Relay
COOLING FAN 1 80A [BLDC (Brushless Direct Current) Motor] Cooling Fan Controller
B+5 50A
Instrument Panel Junction Block
(Fuse - STOP LAMP / Leak Current Autocut Device Fuse / INTERIOR LAMP)
B+4 50A
Instrument Panel Junction Block
(Fuse - DOOR LOCK / POWER HANDLE / SUNROOF / P/SEAT (DRV) / P/SEAT (PASS))
B+3 50A
Instrument Panel Junction Block
(Fuse - S/HEATER DRV/PASS / TAIL GATE / MODULE9 / P/WINDOW RH / P/WINDOW LH)
OPCU 50A Electric Oil Pump Inverter
ESC 1 40A ESC (Electronic Stability Control) Control Module
ESC 2 40A ESC (Electronic Stability Control) Control Module, Multipurpose Check Connector
BLOWER 40A Blower Relay
POWER TAIL GATE 30A Power Tail Gate Module
Engine room compartment fuse panel
