Maintenance
Fuse Name Fuse rating Circuit Protected
MDPS 100A MDPS (Motor Driven Power Steering) Unit
B+6 60A Engine Control Relay, Fuse - HORN / WIPER1 / H/LAMP H / B/ALARM HORN)
B+1 60A Instrument Panel Junction Block (Fuse - IBU1 / IBU2)
B+2 50A Instrument Panel Junction Block (Fuse - E-SHIFTER1 / MODULE1)
E-CVVT 1 40A [THETA II 2.0L T-GDI Engine] E-CVVT Relay
VACUUM PUMP 20A Vacuum Pump Relay
AWD 20A AWD (All Wheel Drive) ECM (Electronic Control Module)
IG 2 20A IG2 Relay
POWER OUTLET 2 10A Front / Rear USB Charger, Front Power Outlet #2,
POWER OUTLET 1 20A Front Power Outlet #1
A/C 10A Air Conditioner Control Module
E-CVVT 3 20A [THETA II 2.0L T-GDI Engine] ECM (Engine Control Module)
To Next Page
