Kia CEED 2018 - Instrument Cluster and Engine Compartment; Warning and Indicator Lights

4
Instrument Cluster / Engine Compartment
a Tachometer
b Speedometer
c Engine coolant temperature
gauge
d Fuel gauge
e Warning and indicator lights
f LCD information screen
a Engine coolant reservoir [8]
b Engine oil filler cap [8]
c Brake/clutch* fluid
reservoir [8]
d Air cleaner [8]
e Engine room fuse box [8]
f Negative battery
terminal [8]
g Positive battery terminal [8]
h Engine oil dipstick [8]
i Radiator cap [8]
j Windscreen washer fluid
reservoir [8]
Instrument cluster [4]
Engine compartment [2]
