331
Safety features of your vehicle
Securing a child restraint seat with
“Tether Anchor” system
(if equipped)
Child restraint hook holders are located
on the floor behind the rear seats.
1. Route the child restraint seat strap
over the seatback.
For vehicles with adjustable headrest,
route the tether strap under the head-
rest and between the headrest posts,
otherwise route the tether strap over
the top of the seatback.
2. Connect the tether strap hook to the
appropriate child restraint hook holder
and tighten to secure the child restraint
seat.
The anchor fitting package consists of:
• Bolt
• Spring washer : 1.5 mm thickness
• Set washer: 1 mm thickness
• Anchor fitting: Conforms to ADR 34/01
OUB031013
OUB031010
OUB031011
■ Type A
■ Type B
OPB039054L
Bolt
(5/16"-17 mm)
Spring washer
Child restraint
hook holder
Set washer
