Kicker CompVR - Page 13

C
C12VR Compact Enclosure Response Curve
C12VR Street Bass Response Curve
C12VR SPL/Deep Bass Enclosure Response Curve
10 Frequency 50 100 Hz 500 1K
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
95
90
85
80
75
70
65
60
55
C
C15VR Compact Enclosure Response Curve
C15VR Street Bass Response Curve
C15VR SPL/Deep Bass Enclosure Response Curve
10 Frequency 50 100 Hz 500 1K
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
95
90
85
80
75
70
65
60
55
Vented Box Response Curves
C15
VR 3.0cu.ft./3.5cu.ft./4.0cu.ft.
C12
VR 1.75cu.ft./2.0cu.ft./2.25cu.ft.
Kicker CompVR Subwoofers
Recommended Applications
Page 13
C
C18VR Compact Enclosure Response Curve
C18VR Street Bass Response Curve
C18VR SPL/Deep Bass Enclosure Response Curve
10 Frequency 50 100 Hz 500 1K
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
100
95
90
85
80
75
70
65
60
C18
VR 4.0cu.ft./5.0cu.ft./6.0cu.ft.
