Here are a couple more examples of the different shape enclosures you can build. The woofer can be mounted
on the same side as the port or the back side of the enclosure can be slanted to fit up against your back seat.. On
the cut sheets we provide, change the dimensions to accommodate the woofer and the vent on the same side.
Make sure the internal volume does not change!
Box Building & Mounting Hints
OR
Kicker CompVR Subwoofers
Recommended Applications
Page 16
0
3
6
9
12
15
18
0 11
BASS
BOOST
(dB)
GAIN
50 200
X-OVER
FREQ. (Hz)
R
0
3
6
9
12
15
18
0 11
BASS
BOOST
(dB)
GAIN
50 200
X-OVER
FREQ. (Hz)
R
Resistance Formulas

Kicker CompVR Specifications

General

Product type	Subwoofer driver
Subwoofer type	-
Subwoofer peak power	800 W
Subwoofer sensitivity	86.9 dB
Subwoofer driver diameter	30 mm
Subwoofer frequency range	25 - 500 Hz
Subwoofer driver diameter (imperial)	12 \
Product color	Black
Voice coil type	Dual
Interface	Terminal

Weight and Dimensions

Width	- mm
