Kicker CompVR - Page 33

Kicker CompVR Subwoofers
Recommended Applications
Page 33
POWER HANDLING:
1000W with 25Hz Subsonic Filter
set at 24db/Octave.
Without subsonic filter 1000W
6.00 cf, Fb=30Hz
.78 cf = Port Vol.
CompVR18-BOX-VENTED-600
Side View
Front View
Cut List: 3/4" MDF
(2) 19 1/2" x 23 3/4" Top & Bottom(A)
(2) 23 3/4" x 27 1/2" Sides(B)
(2) 18" x 27 1/2" Front & Back(C)
(1) 18" x 20" Port(D)
(4) 2" x 2" Gusset(E)
3
20-3/4
29
B
D
E
19-1/2
C
23-3/4
3/4
A
R 3/8
3
3/4
18
∅ 16-5/16
9-3/4
9-3/4
