4
Solo-baric L5 Enclosures
Specifications
Performance
Model: VS10L5 VS12L5 TS10L5
Nominal Impedance [Zn], ohm [per enclosure]
Resonance Frequency [fb or fo], Hz
Sensitivity [SPLo], dB @ 1W, 1m
Effective Piston Area [Sd], in
2
(m
2
)
Power Handling* Watts, Peak (RMS)
Effective Excursion [EXmax™], in (mm)
DC Resistance [Re], ohm [coils in series]
Voice Coil Inductance [Le], mH
Voice Coil Diameter [d], in (mm)
Voice Coil Length [h], in (mm)
Mechanical Q-Factor [Qms]
Electrical Q-Factor [Qes]
Total Q-Factor [Qts]
Force Factor [BL], Tm
Equivalent Volume [Vas], ft
3
(L)
Moving Mass [Mms], oz (g)
Magnet Weight, oz (kg)
Enclosure Top Surface Depth, in (cm)
Enclosure Bottom Surface Depth, in (cm)
Enclosure Height, in (cm)
Enclosure Width, in (cm)
2 or 4
38
92.8
99.98 (.0645)
1100 (550)
.51 (12.9)
3.59
3.90
2 (50.8)
1.36 (34.5)
11.35
.519
.496
17.11
2.43 (68.75)
7.34 (208.1)
77.25 (2.19)
15-1/8 (38.4)
18-1/4 (46.4)
14-5/8 (37.1)
29 (73.6)
2 or 4
36.1
86.4
68.05 (.0439)
900 (450)
.51 (12.9)
3.69
3.80
2 (50.8)
1.36 (34.5)
10.461
.420
.403
16.87
1.51 (42.86)
5.78 (163.9)
77.25 (2.19)
14-1/4 (36.2)
16-5/8 (42.2)
12-1/2 (31.7)
27-3/4 (70.4)
2 or 4
42
89.8
68.05 (.0439)
900 (450)
.51 (12.9)
3.69
3.80
2 (50.8)
1.36 (34.5)
10.461
.420
.403
16.87
1.51 (42.86)
5.78 (163.9)
77.25 (2.19)
6-1/8 (15.6)
9-1/4 (23.5)
14-1/2 (36.8)
17-1/2 (44.4)
Measurements are based on the 4 ohm enclosures. Note: The use of a subsonic filter will significantly increase the power handling. The power handling specifications
in this chart are calculated using a 25 Hz, 24 dB per octave subsonic filter.
*Power Handling Watts RMS without subsonic filter: VS10L5-150, VS12L5-150, TS10L5-450
