Kidde Fire Systems FM-200 ECS Series User Manual

3-490-FM200M-000 September 2004
FM-200
®
ECS Series Engineered Fire Suppression Systems
Table 3-4. Fill Range FM-200 Cylinder/Valve Assemblies for Vertical Installation Only
Part Number
Fill Range Empty Weight
Gross Weight
Min. FIll Max. Fill
lb. kg lb. kg lb. kg lb. kg
90-10001X-001 6-10 3.0-4.5 25 11 30 14 35 16
90-10002X-001 9-20 4.0-9.0 31 14 40 18 51 23
90-10004X-001 18-40 8.0-18.0 38 17 55 25 78 35
90-10007X-001 30-70 14.0-31.5 52 24 82 38 123 56
90-100121-001 54-125 24.5-56.5 98 45 152 69 223 101
90-100125-001 54-125 24.5-56.5 98 45 152 69 223 101
90-100200-101 86-200 39.0-90.5 133 60 219 100 333 151
90-100201-101 86-200 39.0-90.5 133 60 219 100 333 151
90-100350-001 150-350 68.0-158.5 201 91 351 159 555 250
90-100351-001 150-350 68.0-158.5 203 92 341 160 557 251
90-100600-001 258-600 117.0-272.0 335 152 593 270 935 425
90-100601-001 258-600 117.0-272.0 337 153 595 270 937 426
90-100600-100 258-600 117.0-272.0 362 165 620 281 962 437
90-100601-100 258-600 117.0-272.0 362 165 620 281 962 637
90-100900-001 390-900 177.0-408.0 505 230 895 407 1405 639
90-100901-001 390-900 177.0-408.0 505 230 895 407 1405 639
Table 3-3. Dimensions, FM-200 Cylinder/Valve Assemblies for Vertical Installation Only
Part Number Valve w/LLI
Height
(C)
Diameter
(A)
Volume
Valve Outlet Height
CA B
in. m in. m ft.
3
m
3
in. m
90-10001X-001 1½" No 17.30 0.44 7.07 0.18 0.167 0.0047 13.3 0.36
90-10002X-001 1½" No 24.97 0.64 7.07 0.18 0.286 0.0081 21.0 0.53
90-10004X-001 1½" No 26.76 0.68 9.00 0.23 0.572 0.0162 22.8 0.58
90-10007X-001 1½" No 38.83 0.99 9.00 0.23 1.000 0.0283 34.9 0.89
90-100121-001 1½" Yes 35.93 0.92 12.75 0.33 1.788 0.0506 32.0 0.81
90-100125-001 1½" No 35.93 0.92 12.75 0.33 1.788 0.0506 32.0 0.81
90-100200-101 2" No 52.75 1.34 12.75 0.33 2.859 0.0810 47.5 1.21
90-100201-101 2" Yes 52.75 1.34 12.75 0.33 2.859 0.0810 47.5 1.21
90-100350-001 2" No 58.36 1.49 16.00 0.41 5.000 0.1416 53.1 1.35
90-100351-001 2" Yes 58.36 1.49 16.00 0.41 5.000 0.1416 53.1 1.35
90-100600-001 2½" No 56.72 1.45 22.00 0.56 8.572 0.2427 50.5 1.28
90-100601-001 2½" Yes 56.72 1.45 22.00 0.56 8.572 0.2427 50.5 1.28
90-100600-100 3" No 58.00 1.47 22.00 0.56 8.680 0.2460 50.5 1.28
90-100601-100 3" Yes 58.00 1.47 22.00 0.56 8.680 0.2460 50.5 1.28
90-100900-001 3" No 70.00 1.78 24.00 0.61 13.000 0.3680 62.0 1.57
90-100901-001 3" Yes 70.00 1.78 24.00 0.61 13.000 0.3680 62.0 1.57
