Kidde 7DCO User Manual

9
5. Installaon Instrucons – Mounng
THIS ALARM MUST BE INSTALLED BY A COMPETENT PERSON AND IS TO BE INSTALLED AC-
CORDING TO THESE INSTRUCTIONS
Wall-mounng
1. Drill two holes in a wall 7.8 cm apart (you may wish to use the back-plate for guidance)
2. Insert the two rawl-plugs, that are supplied, into the holes
3. Insert the two screws as supplied into the holes ensuring enough of the screw scks
out of the wall (approx. 3mm)
4. Hook the alarm over the screws
Free-standing
1. No more than 1 metre from the floor (to minimise this risk of the alarm being
permanently damaged should it be knocked to the floor from a greater height)
2. Make sure the alarm is in the upright posion and not lying flat on the surface
2530-7202-06_7CO(Caravans):_ 2015.2.9 10:18 AM Page 9

Kidde 7DCO Specifications

General

Type	Carbon Monoxide Alarm
Power Source	Battery
Battery Type	2 AA batteries
Display	Digital Display
Alarm	85 dB at 10 feet
Test/Reset Button	Yes
Sensor Type	Electrochemical
Operating Temperature	40°F to 100°F (4.4°C to 37.8°C)
Features	peak level memory
Operating Humidity	10% to 95% relative humidity (non-condensing)
Certifications	UL 2034
