Chapter 1: Introduction
Alarmline II Digital Linear Heat Sensor Cable Technical Manual 7
Table 6: AD105 range
AD105 AD105N AD105P AD105SS
105°C (221°F)
PVC Nylon Polypropylene
Stainless steel
over PVC
White Black White White
3.6 mm
(±0.12 mm)
0.142 in.
(±0.005 in.)
4.44 mm
(±0.12 mm)
(0.175 in.
(±0.005 in.)
4.5 mm
(±0.12 mm)
(0.177 in.
(±0.005 in.)
4.1 mm
(±0.12 mm)
(0.161 in.
(±0.005 in.)
2 × tri-metallic conductors Ø 0.912 mm (0.036 in.)
69°C (156°F) max.
−10°C (14°F) min.
−40°C (−40°F) min.
50 mm (2 in.) min., extended to 100 mm (4 in.) for low temperature
environments
30 VAC, 42 VDC max.
1 kV tested protective outer coat
91 Ω/km (27.7 Ω/1000 ft.) max. per conductor at 20°C
<73 pF/m (<22 pF/ft.)
<1.65 µH/m (<0.5 µH/ft.)
Table 7: AD185 range
AD185N AD185SS
185°C (365°F)
Nylon Stainless steel over PVC
Red White
4.44 mm (±0.12 mm)
(0.175 in. (±0.005 in.)
5 mm (±0.12 mm)
(0.197 in. (±0.005 in.)
2 × tri-metallic conductors Ø 0.912 mm (0.036 in.)
125°C (257°F) max.
−10°C (14°F) min.
−40°C (−40°F) min.
50 mm (2 in.) min., extended to 100 mm (4 in.) for low temperature
environments
