Chapter 1: Introduction
8 Alarmline II Digital Linear Heat Sensor Cable Technical Manual
AD185N AD185SS
30 VAC, 42 VDC max.
1 kV tested protective outer coat
91 Ω/km (27.7 Ω/1000 ft.) max. per conductor at 20°C
<90 pF/m (<27 pF/ft.)
<1.62 µH/m (<0.49 µH/ft.)
Table 8: AD218 range
AD218 AD218SS
UL/ULC approval at 218°C (424°F)
FM approval at 235°C (455°F)
Silicone rubber Stainless steel over silicone
Green Green
5 mm (±0.1 mm)
(0.196 in. (±0.004 in.)
5.5 mm (±0.11 mm)
(0.216 in. (±0.04 in.)
2 × tri-metallic conductors Ø 0.912 mm (0.036 in.)
170°C (338°F) max.
−10°C (14°F) min.
−40°C (−40°F) min.
63.5 mm (2.5 in.) min., extended to 127 mm (5 in.) for low temperature
environments
70 VAC, 100 VDC max.
5 kV tested protective outer coat
90 Ω/km (27.4 Ω/1000 ft.) max. per conductor at 20°C
<85 pF/m (<26 pF/ft.)
<2.00 µH/m (<0.61 µH/ft.)
