Kidde VM-1 Technical Reference Manual

Chapter 7: Service and troubleshooting
P/N 3101890-EN • REV 006 • ISS 21JUN18 143
Table 53: R-Series / K-R-Series annunciator local trouble pseudo points
Address [1]
Label Source Description
xx90
Annunciator
Communications
ANN A communication fault occurred between the panel
and an R-Series / K-R-Series annunciator
xx91
Annunciator RAM
Supervision
ANN An R-Series / K-R-Series annunciator RAM fault
was detected
xx92
Annunciator CH1
Communications
ANN N/A
xx93
Annunciator
Configuration
ANN • The R-Series / K-R-Series annunciator
configuration does not match the actual
hardware
• The R-Series / K-R-Series expander is not
communicating with the R-Series / K-R-Series
annunciator
xx94
Annunciator Class A ANN N/A
xx95
Ann DB Supervision ANN The R-Series / K-R-Series annunciator database is
corrupt
xx96
Annunciator Code
Supervision
ANN The R-Series / K-R-Series annunciator database is
corrupt
[1] Up to 30 annunciators can be configured per cabinet. The first two digits in the address column represent the
annunciator number. See Table 54.
Table 54: Annunciator address set
Annunciator Address set Annunciator Addresses set
1 0290-0296 16 4790-4796
2 0590-0596 17 5090-5096
3 0890-0896 18 5390-5396
4 1190-1196 19 5690-5696
5 1490-1496 20 5990-5996
6 1790-1796 21 6290-6296
7 2090-2096 22 6590-6596
8 2390-2396 23 6890-6896
9 2690-2696 24 7190-7196
10 2990-2996 25 7490-7496
11 3290-3296 26 7790-7796
12 3590-3596 27 8090-8096
13 3890-3896 28 8390-8396
14 4190-4196 29 8690-8696
15 4490-4496 30 8990-8996
