Kidde VM-1 Technical Reference Manual

Appendix B: Addresses
192 P/N 3101890-EN • REV 006 • ISS 21JUN18
Hardware layer device addresses
Table 77 lists the device addresses for points on the VM-1 hardware layer.
Table 77: VM-1 hardware layer device addresses
Card
Device or circuit Address
PS10
-4B NAC/AUX 1
NAC/AUX 2
NAC/AUX 3
NAC/AUX 4
PP020001
PP020002
PP020003
PP020004
VM
-CPU
Loop Circuit 1
Loop Circuit 2
Detectors
Modules
Detectors
Modules
PP030001 to PP030125
PP030126 to PP030250
PP030251 to PP030375
PP030376 to PP030500
VM
-SLCXB
Loop 1
Loop 2
Detectors
Modules
Detectors
Modules
PP050001 to PP050125
PP050126 to PP050250
PP050251 to PP050375
PP050376 to PP050500
VM
-PMI Default_Normal_PP_08
Default_Alert_PP_08
Default_EVAC_PP_08
Default_Pre_PP_08
MSG_005 to MSG_255
PP060001
PP060002
PP060003
PP060004
PP060005 to PP080255
ACHS
1 Channel_1_Relay_Confirmation
Channel_2_Relay_Confirmation
Channel_3_Relay_Confirmation
Channel_4_Relay_Confirmation
PPCC0003
PPCC0004
PPCC0005
PPCC0006
ACHS
2 Channel_1_Relay_Confirmation
Channel_2_Relay_Confirmation
Channel_3_Relay_Confirmation
Channel_4_Relay_Confirmation
PPCC0003
PPCC0004
PPCC0005
PPCC0006
ACHS
Channel_1_Relay_Confirmation
Channel_2_Relay_Confirmation
Channel_3_Relay_Confirmation
Channel_4_Relay_Confirmation
PPCC0003
PPCC0004
PPCC0005
PPCC0006
