Kidde VM-1 Technical Reference Manual

Appendix B: Addresses
194 P/N 3101890-EN • REV 006 • ISS 21JUN18
Remote annunciator device addresses
Table 79 on page 197 lists the device addresses for points on RLED-C and K-RLED-C remote annunciators,
RLED24 and K-RLED24 expanders, GCI and GCI-NB graphic annunciator cards, and GCIX expander cards. See
also Figure 59, Figure 60, and Figure 61.
Note: Switch addresses do not apply to R-Series or K-R-Series remote annunciators and expanders. RLCD / K-
RLCD and RLCD-C / K-RLCD-C remote annunciators do not have addressable points.
Figure 59: RLED-C / K-RLED-C and RLED24 / K-RLED24 LED numbering
Controls Enabled
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
LED01
LED16
LED17
LED32
LED01
LED16
LED17
LED32
LED33
LED48
RLED-C /
K-RLED-C
RLED24 /
K-RLED24
