5.3 Seat location for semi-universal installation
Semi-universal installation of the child restraint system (A) is only possible in
vehicle seat positions which are equipped with ISOFIX anchorage points. The
kiddy phoenixfix 3 can be connected to these ISOFIX anchorage points with the
k-fix
+
connectors (D).
The kiddy phoenixfix 3 child restraint system (A) can be installed in vehicles and
on seats which are listed in the type list.
The type list is continuously updated. The latest version can be found online at
http://www.kiddy.de/vehicletypelist
The manufacturer recommends the semi-universal installation of the child
restraint system (A) with the k-fix
+
connections (D) when possible.
6 Semi-universal installation in the vehicle with k-x
+
Actuate the unlocking handle (P) at the front underneath the leg extension (J)
(Fig. 12; No. 1). The k-fix
+
connectors (D) now automatically extend out of the
back of the seat (E).
Rotate the connectors (D) 180° so that the connection openings point towards
the vehicle seat (Fig. 13).
Check whether the connector hooks are open by sliding the two unlocking
mechanisms (S) forward. (Fig. 14). If the locking indicators (R) do not show ‘green’,
the connector hooks are open (Fig. 14).
Place the kiddy phoenixx 3 on a vehicle seat which allows for
semi-universal installation (point 5.3) and adjust the vehicle
seat as necessary according to point 5.1.
Now slide both k-fix+ connectors (D) onto the metal mounts (ISOFIX anchorage
points) and push firmly against them so that the connectors (D) lock in place
(Fig. 15).
!
