Assemble the Corvette Race Car
1
1. Locate a wheel marked “REAR”.
Slide a wheel onto the axle with
“REAR” facing toward vehicle. Fit
the wheel into the gear box.
NOTE: For the rear wheels, a large
washer is NOT needed before sliding
a wheel onto the axle.
Then slide a wheel cover onto the
axle, fitting the three locating pins
into the holes.
2
2. Slide a small washer onto the axle.
Attach a nut onto the axle and
tighten snugly with the nut wrench
until you can see about two threads
on the axle. Do not overtighten.
Repeat steps 1 and 2
to attach the other
rear wheel.
Attach Rear Wheels
2a
６
To Next Page
