Product Description
DDC4200e
J
Page 4 / 10
2.60-10-210-01-EN | 2020-12-11
NOTE
The RS232 or RS485 interface is activated by means of configuration.
Only one of the two interfaces can be used. The default setting is inactive.
You can find further information in the DDC4000 project planning documentation
Section "SY_Serial" Objects
NOTE
Max. 63 fieldbus addresses or max. 16 switch cabinet bus addresses are managed on the two CAN
buses.
The maximum number of connectible input/output modules depends on the selected device types.
More information can be found in the DDC4000 project planning documentation.
Displays Touchscreen with active backlit ¼ VGA color active matrix LCD display
14 cm screen size (5.7 inch)
Memory 4 GB flash; 512 MB RAM)
Operating system Embedded Linux
Mains failure
data backup
7 years, battery-buffered clock module
Degree of protection IP20
Overvoltage category III
Rated impulse voltage 800V
Level of contamination 2
How It Works Type 1
Ambient temperature 0 °C to 50 °C
Ambient humidity During operation: 20% to 80% r.h., non-condensing
Out of operation: 5% to 90% r.h., non-condensing
Housing 19" plastic short enclosure, quadruple enclosure with base and extra con-
nections for Ethernet RJ45 and RS232
WxHxD: 202 x 132 x 137 mm
Front panel cutout 200.4 mm x 112.0 mm
Weight 1.15 kg
Label CE
