Kieback&Peter DDC4200e - Page 8

Product Description
DDC4200e
J
Page 8 / 10
2.60-10-210-01-EN | 2020-12-11
Sensor and actuator connection
!
CAUTION
The GND wiring specified in the wiring diagram (Y GND, K GND, B GND) must be observed.
Incorrect GND wiring may lead to errors in measurement.
Y1..Y24
21
24VAC
24V
0V
24V 0V Y
B1..B24
24VAC
24V
0V
24V 0V b
0..10V DC
41
15
61
K1..K32 B1..B24
2
k1..k32
Y
GND
B
GND
24 VDC
0 VDC
ϑ
35
36
37
+
-
21
0..10VDC
Y
GND
22
