Datasheet 1.10-60.010-01-EN
RBW301-C, RBW302-C, RBW304-C, RBW305-CProduct Description
Issue 2017-07-20
Item
Technical Data
Accessories (not included in delivery)
RBW301-C Room control module with room temperature sensor and display, settings made
using knob and confirmation key (room temperature setpoint, timer functions)
RBW302-C All features of RBW301-C plus presence button
RBW304-C All features of RBW301-C plus buttons for fan control
RBW305-C All features of RBW301-C plus buttons for fan control, presence button
Nominal voltage DC 12 V, ± 10%, 0.96 W
Power consumption 0.6 W backlighting (OFF)
0.96 W backlighting (ON)
Measured value Room temperature of spaces in homes or commercial premises
Measuring system Integrated digital sensor
Display and
controls
■ Backlit display: Feedback, presence, fan status, heating/cooling,
window contact, weekly schedule, time, date, project-specific
messages, service level
■ Knob with confirmation key for setting the temperature, time and weekly
schedule; display of service data
Keys:
Fan control level increasing: Fan on, increased speed
Fan control level decreasing: Decreased speed, fan off
Fan in automatic mode (fan speed specified by controller)
Presence button: Switch to present or absent
Interfaces 4-wire terminal or RJ9 jack
Measuring range 0 °C to 50 °C
Relative measuring accu-
racy
0.1 K
Housing Plastic housing, RAL 9010 (pure white)
Other colors on request
Protection class III
Degree of protection IP30
Ambient temperature 0 °C to 50 °C
Ambient humidity During operation: 20% to 80% r.h.; non-condensing
Out of operation: 5% to 90% r.h.; non-condensing
Installation Screw mounting on standard flush-mounted box
Weight 0.12 kg
Dimensions WxHxD mm 90 x 90 x 32,5;
Depth in wall 9.5
Z146 Adapter frame for direct wall mounting
