-4-
(9) Power requirements: 90 V - 126 V, 194 V - 253 V,
selectable with plug; 50/60 Hz AC
(10) Dimensions: 134 W x 180 H x 250 D mm
(5.28 W x 7.09 H x 9.84 D in.)
Maximum dimensions: 140 W x 250 H x 295 D mm
(5.51 W x 8.07 H x 11.61 D in.)
(11) Accessories: Instruction manual ---------------------------------------- 1
Fuse, 0.1 A S.B ------------------------------------------ 1
2.2 Power Consumptions and Weights
AVM13, AVM15: Approx. 5VA, approx, 2.8 kg (6.2 lbs)
AMV23, AVM25, AVM23R, AVM25R: Approx. 8VA, approx. 3.1kg (6.8lbs)
2.3 Measuring Voltage Ranges
AVM
13
23
23R
15
25
25R
-70 -60 -50 -40 -30 -20 -10 0 10 20 30 40 dB
mV V
0.3 1 3 10 30 10
0
30
0
131030 10
0
0.5 1.5 5 15 50 15
0
50
0
1.5 5 15 50 15
0
2.4 Maximum Allowable Input Overvoltrages (DC + AC peak)
300 µV - 100 mV ranges and 500 µV - 150 mV ranges: 120 V
300 mV - 100 V ranges and 500 mV - 150 V ranges: 500 V
(AC components not higher than 1 kHz, application period not longer than 1 minute)
