6-6Names and Functions of Controls PASSERIES
[14] DC OUTPUT
Output terminal.
• To prevent the possibility of electric shock, be sure to
turn off the POWER switch when handling this termi-
nal.
• Be sure to attach the output terminal cover after wir-
ing the load.
[15] J1
Connector for selecting analog remote control, p
arallel/series opera-
tion, and other functions. For details, see "4.1 Analog Remote Con-
trol" and "4.2 Remote Monitoring".
[16] TP-BUS
Connector used to connect to a Kikusui's PIA4800 Series Power Sup-
ply
Control
ler using a twisted-pair cable when digital remotely con-
trolling the unit.
For details, see "4.3 Digital Remote Control".
[17] (Protective conductor terminal)
Terminal used to ground the unit to an electrical ground (safety
ground).
• To prevent the possibility of electric shock, be sure to
turn off the POWER switch when handling this termi-
nal.
[18] Sensing terminal
Terminal used to connect the sensing wires.
For
details, see "3.6 Remote Sensing".
[19] Exhaust port
Exhaust port used to exhaust the internal heat using a fan motor.
Se
cure suff
icient space around the exhaust port and the unit for ade-
quate ventilation.
To Next Page
