5. Run leads to front of gravity box and connect to a
12 Volt D.C. electrical supply. The white wire (+)
must be assembled to the positive supply of the
power source. The black wire must be connected to
the ground of the power source (Figure 3-15).
6. Check auger for proper installation and turn on
electrical and hydraulic power supplies. The auger
will function when the “ON” button is pressed. To
stop auger, press “OFF” button on switch.
IMPORTANT! WHEN ELECTRICAL POWER
SUPPLY IS STOPPED, THE AUGER WILL
AUTOMATICALLY SHUT-OFF, EVEN THOUGH
HYDRAULIC POWER IS STILL BEING SUPPLIED.
CAUTION! WHEN INSTALLING HYDRAULIC
LINES TO SOURCE, BE SURE TO CONNECT TO
PROPER PORTS. IF LINES ARE REVERSED, THE
AUGER WILL START IMMEDIATELY, ONCE THE
FLOW IS INITIATED. TO PREVENT INJURY BE
SURE THAT ALL OBJECTS AND PERSONNEL ARE
CLEAR OF THE AUGER FLIGHTING WHEN
OPERATING AUGER FOR THE FIRST TIME.
NOTE: To reverse auger, turn off power supply and
reverse lines on ports. Take note that when hydraulic
power is turned back on, the auger will operate even
though the switch is in the “OFF” position. To halt
auger, turn switch to “ON”.
IMPORTANT! WHEN TURNING ON
HYDRAULIC SUPPLY, BE AWARE OF WHEN THE
AUGER IS OPERATING. FOR FORWARD MOTION,
THE AUGER WILL OPERATE WHEN THE SWITCH
IS TURNED “ON”. FOR REVERSING MOTION, THE
HYDRAULIC LINES MUST BE REVERSED AND
THE SWITCH MUST BE IN THE “OFF” SETTING.
