Parts for Hydraulic Augers
Item Part No. Description Item Part No. Description
1 9807 5/16" Locknut 38 9389-034 5/16" X 2" HCS
2 91263 3/8" Flanged Nut 39 100610 Hydraulic Oil Pipe (112)
3 9403-96747 5/16" X 1" RD.HD.Mach.Screw 100611 Hydraulic Oil Pipe (114)
4 9394-008 7/16" Fin. Hex Nut 103932 Hydraulic Oil Pipe (115)
5 9391-034 5/32" X 1-1/4" Cotter Pin 40 100648 Auger Valve Seal Kit
6 94981 1/2" Locknut 41 100651 Discharge Tube Clamp
7 9389-055 3/8" X 1" HCS 42 9928 3/8" Locknut
8 9394-006 3/8" Fin. Hex Nut 43 100606 Auger Control Valve
9 9394-002 1/4" Fin. Hex Nut 44 100984 Decal (Model 112)
10 9405-064 1/4" Flat Washer 100985 Decal (Model 114)
11 100123 30" R.H. Mounting Bracket (350) 103949 Decal (Model 115)
100124 34" R.H. Mounting Bracket (385 / 390) 45 9389-060 3/8" X 2-1/4" HCS
104927 62" R.H. Mounting Bracket ("55" Series) 46 9119 Auger Winch w/ Handle
12 100126 30" L.H. Mounting Bracket (350) 47 101410 #7 Fast Eye Pulley
100127 34" L.H. Mounting Bracket (385 / 390) 48 9405-070 5/16" Flat Washer
104929 62" L.H. Mounting Bracket ("55" Series) 49 101486 Winch Cable Ass'y (10'6")
13 100128 Swing Bracket 50 105260 Safety Chain, Trans. Bracket
14 9390-100 1/2" X 1-1/4" HCS 51 9405-090 Washer 1/2"ID X 1 3/4"OD
15 100131 Hydraulic Hose (350 / 385 / 390) 52 9390-101 HCS 1/2 x 1 1/2
103967 Hydraulic Hose ("55" Series) 53 103073 12' Brush Flighting
16 100132 Hose Coupler Bracket 103074 14' Brush Flighting
17 100135 Auger Rest 103934 15' Brush Flighting
18 100137 Hose Bracket 54 103376 Hyd. Auger Safety Screen
19 100138 Flexible Discharge Tube 55 9389-005 1/4" X 1" HCS
20 100141 12' Auger Tube 56 103417 Decal "Keep Hands Out"
100190 14' Auger Tube 57 91514 Quick Link, 1/4"
103936 15' Auger Tube 58 103740 1/4" Chain (3-Link)
21 100147 12' Auger Screw 59 103741 Winch Bracket
100193 14' Auger Screw 60 2745-B Winch Clamp
103933 15' Auger Screw 61 103907 Door Clip (Auger Boxes)
22 100151 Fertilizer Spout 62 103908 Clean-Out Door
23 100152B Fertilizer Spout Bracket 63 103920 Transport Bracket Complete
24 22054 Auger Rope (6Ft.) 64 9389-001 1/4" X 1/2" HCS
25 9640 1/2" Steel 90 Street Ellbow 65 9936 1/4" Locknut
26 9389-031 5/16" X1-1/4" HCS 66 20758 Auger Safety Cable (72")
9390-100 1/2" X 1- 1/4" HCS 67 103998 Swivel Cable Assembly
27 9404-019 5/16" Med. Lockwasher 104931 Swivel Cable Assembly ("55" Series)
9404-025 1/2" Med. Lockwasher 68 100120 30" Auger Box Weldment (350)
28 9394-004 5/16" Fin. Hex Nut 100121 34" Auger Box Weldment (385 / 390)
9394-010 1/2" Fin. Hex Nut 105032 62" Auger Box Weldment ("55" Series)
29 9389-028 5/16" X 3/4" HCS 69 100650 Motor Seal Kit
30 9390-057 3/8" X 1-1/2" HCS 70 100630 O-Ring
31 9405-076 3/8" Flat Washer 71 93558 Electric Shock Decal
32 9389-007 1/4" X 1-1/2" HCS 72 95445 Oil Leak Decal
33 9404-017 1/4" Med. Lockwasher 73 91043 Plastic Rivet
34 105251 1/4" Spring Clip 74 105234 Rubber Seal
35 9404-023 7/16" Med. Lockwasher 75 95989 3/8" Eye Bolt
36 9163 3/4" -16 Slotted Nut 76 9390-030 5/16" X 1" HCS
37 100607 Hydraulic Motor 77 105457 Plastic Chain Cover
