Kilsen KAL714C - Maintenance and Testing; Specifications; Regulatory Information

2 / 16 P/N 10-5151-501-108-02 • ISS 09JUN21
Addressing
Each module requires a numeric address for identification
purposes. This is set by using DIP switches 1 to 8.
The module uses four addresses: The configured address plus
the next three numbers (for example, 201, 202 and 203 if the
configured address is 200).
By switching DIP switches 1 to 7 to the ON position, the
module can be addressed from 128 to 252.
For further information, refer to address tables at the end of
this document.
Note: By switching DIP switch 8 to the ON position, the KFP-A
panel allows the module to be addressed from 1 to 125.
Caution: Do not attempt to use DIP switch 8 with any control
panel other than the KFP-A. If you place DIP switch 8 in the
ON position with any other type of control panel, this action
may damage or destroy the module.
Status LED
The Status LED is lit constantly during alarm.
Maintenance and testing
Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
To test the module:
1. Remove a detector head from its base or activate a
manual call point connected to the module detection zone.
2. If the status LED and control panel fail to indicate the test
all connections should be checked and the module
address verified.
Specifications
Operating voltage
22 to 38 VDC
Loop current consumption
at 24 VDC (standby)
at 35 VDC (standby)
Alarm
110 µA
135 µA
<5.0 mA
Current consumption
24 VDC aux. supply (standby)*
24 VDC aux. supply (alarm)*
200 µA
<360 mA
End
-of-line resistor 4.7 kΩ
Operating temperature
Storage temperature
−10 to +50ºC
−10 to +70ºC
Relative humidity
10 to 95% (noncondensing)
Weight
835 g
Dimensions
223 × 173 × 80 mm
* Excluding loop devices
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation
(EU) 305/2011 and Delegated Regulations (EU) 157/2014 and
(EU) 574/2014.
For detailed information, see the product Declaration of
Performance (available at firesecurityproducts.com
).
Certification
Certification body
0370
Declaration of
Performance number
360-4109-0699
Year of first CE marking
08
Product identification
KAL714C
Intended use
See the product Declaration of Performance
Declared performance
See the product Declaration of Performance
Manufacturer
Carrier Manufacturing Poland Spòlka Z o.o.
Ul. Kolejowa 24, 39-100 Ropczyce, Poland.
Authorized EU manufacturing
representative:
Carrier Fire & Security B.V.,
Kelvinstraat 7, 6003 DH Weert, Netherlands
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
equipment, or dispose of it at designated
collection points. For more information see:
recyclethis.info
.
Contact information and product
documentation
For contact information or to download the latest product
documentation, visit firesecurityproducts.com
.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS.
CARRIER FIRE & SECURITY B.V. CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED DEALER” OR
“AUTHORIZED RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers
and product safety information, please check
https://firesecurityproducts.com/policy/product
-
warning/
or scan the QR code:
