1.2. Technical specifications
1.2.1 General technical specifications
Display Backlight graphic LCD
Size : 85 x 51 mm
Resolution : 240 x 180 pixels
Connection measuring ports Ribbed connectors for tubes Ø 6 x 2 mm
Connection generation ports Quick-coupling connectors DN2.7
Power supply 230 Vac ±10 % / 50-60 Hz or on battery
Consumption 19 W
Autonomy 8 hours
PC interface USB
Operating temperature From 0 to +50 °C
Storage temperature From -10 to +70 °C
Environment Air, non-aggressive gases, non-corrosive gases
Languages French, English
Weight 4.5 kg
Conformity Directives EMC/2004/108/CE and EN 61010-1
Fuse on the phase and on
the neutral
Time delay 1 A 250 V
Device must be connected to the protective ground
1.2.2 Technical specifications in measurement and pressure generation
GP 500 0-2500 Pa :
Measuring range From -2500 to +2500 Pa
Precision* in measurement ±0.15 % of the reading ±0.8 Pa
Generation range From -2500 to -5 Pa and from +5 Pa to +2500 Pa
Precision* in generation 1 Pa
Resolution From -2500 to -1000 Pa : 1 Pa
From -1000 to -100 Pa : 0.1 Pa
From -100 to +100 Pa : 0.01 Pa
From +100 to +1000 Pa : 0.1 Pa
From +1000 to 2500 Pa : 1 Pa
Autozero Automatic
Manual (keypad)
Units
Pa, daPa, hPa, mmH
2
O, mmHg, mbar, inWg
*All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out
with calibration compensation
