Kind XT - Front - Back Panel; Side View; Vista Fronte - Retro - Fianco; Front Panel; Rear Panel

Page 6KIND XT models Power Amplifiers
models
P ROFESSIONAL POWER AMPLIFIER
Handcrafted in Italy
Model
POWER
1
0
LEVEL B
CLIP/LIM
LEVEL A
SIGNAL K.C.C.S. ACTIVE HI-TEMP PROTECT
(dB)
0
23
18
14
9
5
1.
5
∞
49
36
29
(dB)
0
23
18
14
9
5
1.
5
∞
49
36
29
ACTIVE
K.C.C.S.
HI-TEMP
PROTECT
SIGNAL
CLIP/LIM
XT4000
3
3
4
5
1
2
133mm
57mm
483mm
6
10 9
6 8 7
CAUTION:
replace fuse only with
correct type and rating
WARNING:
To reduce the risk of fire or electric
shock do not expose equipment to
rain or moisture, do not remove cover,
no use serviceable parts inside, refer
servicing to qualified service personnel.
See operating manual before using.
I - 28066 Galliate - NO
MADE IN ITALY - EC
A
B
STEREO
BRIDGE
INPUTS
INPUT CONNECTIONS:
XLR Pin 2 +
TRS Tip +
BRIDGE MODE:
use A input
OUTPUT 1
CHANNEL A CHANNEL B
PIN 1 + Pos PIN 2 + Pos
PIN 1 - Gnd PIN 2 - Gnd
BRIDGE OUTPUT
PIN 1 + Pos
PIN 1 - Gnd
OUTPUT 2
CHANNEL B CHANNEL A
PIN 1 + Pos PIN 2 + Pos
PIN 1 - Gnd PIN 2 - Gnd
LIMITER
OUT
IN
KIND Audio
Galliate (NO), Italy
Made in E.U.
Model: XT4000
Output PWR per CH/Imp: 1800/4
230VAC 50/60Hz 12A SERIAL
133mm
440mm
453mm
44mm
13
17 17
15 16
14
12 12
11
Front Panel
Rear Panel
Side View
57mm
9
