King Pigeon Hi-Tech. Co., Ltd. Ver 1.0
GSM/GPRS/3G/4G/Cloud
Network Fault Monitoring Alarm
Table of contents
1. Brief introduction -----------------------------------------------------------------------------------------------------3
2. Safety directions ------------------------------------------------------------------ ------------------------------------3
3. Standard packing list --------------------------------------------------------------------- ---------------------------3
4. Mainly features ------------------------------------------------------------------------------------------------------ 4
5. Technical specifications--------------------------------------------------------------------------------------- ------5
6. Physical layout ----------------------------------------------------------------------------------------------- - -------5
7. Reset the unit ------------------------------------------------------------------------------------ ----------- ---------7
8. Configuration Software----------------------------------------------------------------------- ----------- ----------7
9. Settings&Operation(SMS command)------------------------------------------------------- -------------------13
10. Data Communication Protocol---------------------------------------------------------------------- ------------20
11. Warranty----------------------------------------------------------------------------------- ------------- -------------22
【UPGRADE HISTORY】
【Model List】
Model
GSM/3G/4G
Description
Input/Output Type
DC Input
RTU5023
Optional
Environmental Monitoring Alarm
AM2301 Temperature&Humidity Sensor
9-36V
DC
RTU5026
Temperature Monitoring Alarm
DS18B20 Temperature Sensor
RTU5027A
Analog Transducer Monitoring Alarm
4~20mA Analog Input
RTU5027V
Analog Transducer Monitoring Alarm
0~5V Analog Input
RTU5028
AC/DC Power Monitoring Alarm
12VDC Output
RTU5028E
Network Fault Monitoring Alarm
Relay output
RTU5029SA
Phase Loss Monitoring Alarm
3 Phase Input,12VDC Output
RTU5029SB
Phase Loss Monitoring Alarm
Single Phase Input ,12VDC Output
DATE
VERSION
DESCRIPTION
2019-07-18
Ver 1.0
RTU5028E Origin Version
2020-01-07
Ver 1.1
Optimized configuration software connection
This handbook has been designed as a guide to the installation and operation of RTU5029S temperature&
humidity&voltage&power Failure alarm and monitor.
Statements contained in the handbook are general guidelines only and in no way are designed to supersede the
instructions contained with other products.
We recommend that the advice of a registered electrician be sought before any Installation work commences.
King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for any loss or damage including
consequential damage due to reliance on any material contained in this handbook.
King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for GSM Network upgrading or SIM
Card upgrading due to the technology specifications contained in this handbook.
