King Pigeon RTU5028 - Mainly Features; Technical Specifications

Page
4
of
22
King Pigeon Hi-Tech. Co., Ltd. Ver 1.0
GSM/GPRS/3G/4G/Cloud
Network Fault Monitoring Alarm
4. Mainly Features
 GSM/GPRS/3G/4G/Ethernet network communication,automatic connect to cellular network when wired
network failed;
 Network failure + power failure + network cable monitoring, remote monitoring the status of network device
in many aspects;
 Support monitoring up to 7 network devices simultaneously;
 Inbuilt MCU monitoring power supply input voltage value, measure range is 0~36V, no need additional sensor
to save cost;
 Up to 10 authorized phone numbers, can program to receive specified alarm message;
 Can set timer report and every x hours automatically send its status/value to the authorized number;
 Support remotely read 100 historic data via SMS or configuration software ;
 Rechargeable backup battery inside can last 6 hours;
 Modular structure design, replace a module can upgrade the network from 2G to 3G/4G or 3G to 4G;
 Compatible wall installation and DIN35mm industrial rail installation;
 Support Modbus RTU,Modbus TCP and MQTT protocol, can be connected to cloud platform.
5. Technical specifications
Item
Reference Scope
DC Power supply
Standard adapter:12VDC，Range 9~36VDC
Power consumption
Standby：12V/100mA；Working Max：12V/380mA
GSM/3G/4G
GSM frequency: 850/900/1800/1900MHz
3G/4G: Optional: WCDMA/TDD-LTE/FDD-LTE
Communication
methods
SMS phone, GPRS/3G/4G wireless cellular network, Ethernet wired network
SIM interface
Support 3V or 1.5V SIM Card
External antenna
SMA Antenna interface, 50 Ohm, Gain: 3dB
